Fig. 35 – Hoshizaki KM-61BAH User Manual
Page 84
79
Fig. 35
KM-151BWH
Icemaking Water Supply
Inlet 1/2” FPT
Bin Drain Outlet
3/4” FPT
Condenser Water
Outlet 1/2” FPT
Condenser Water
Inlet 1/2” FPT
Shut-off Valve
Drain Valve
Shut-off Valve
Drain Valve
Two-inch (5 cm)
air gap
Drain
Floor
Separate piping to approved drain.
Leave a two-inch (5 cm) vertical air
gap between the end of each pipe
and the drain.
