Fig. 20, Fig. 21 – Hoshizaki KM-61BAH User Manual
Page 67
62
7) The Bin Control Switch (KM-61BAH) pulled out of the Storage Bin has the internal
structure as shown below.
Fig. 20
Retainer
Evaporator
Pump Motor
Hold here and pull toward you
Stopper (A) [both sides]
Slide Rail
[both sides]
Pull
Fig. 21
Reed Switch
Lead Hook
Bin Switch Case
Bin Switch Plate
Reed Switch Cover
Stopper (B) [both sides]
* Fit in Stopper (A)
