8 REAR-PANEL CONNECTIONS
REAR-PANEL CONNECTIONS
¡ AM Antenna
™ FM Antenna
£ Preamp Outputs
¢ Subwoofer Output
∞ A-BUS Connector
§ Surround Speaker Outputs
¶ Front Speaker Outputs
• Fan Vents
ª Center Speaker Outputs
‚ Surround Back/Multiroom Speaker Outputs
⁄ AC Power Cord
¤ Switched AC Accessory Outlet
‹ Unswitched AC Accessory Outlet
› Video Monitor Outputs
fi DVD Video Inputs fl Video 1 Video Inputs
‡ Video 1 Video Outputs
° Video 2 Video Inputs
· Video 2 Video Outputs
a Video 3 Video Inputs
b Component Video Monitor Outputs
c DVD Component Video Inputs
d Component Video 1 Inputs
e Component Video 2 Inputs
f Multiroom IR Input
g Remote IR Input
h Remote IR Output
i Remote IR Carrier Output
j RS-232 Port
k Coaxial Digital Audio Output Multiroom Audio Outputs
Coaxial Digital Audio Inputs
CD Audio Inputs
Optical Digital Audio Output
DVD Audio Inputs
Tape Inputs
Tape Outputs
Optical Digital Audio Inputs
Video 1 Audio Inputs
Video 1 Audio Outputs
Video 2 Audio Inputs
Video 2 Audio Outputs
8-Channel Direct Inputs
Video 3 Audio Inputs
