CONFIGURING THE REMOTE 49

CONFIGURING THE REMOTE

above, except that in Steps 4 and 5, select the same
device for both the DEVICE IN USE on the left
side of the bottom line and the PUNCH-THROUGH
device. In the example used, the display to return the
remote to default settings will appear as shown in
Figure 63.

Figure 63

Channel Punch-Through
Channel punch-through allows the Channel Up/Down
buttons to send commands to a different device than
the one selected for other commands. For example,
you may wish to use a cable box or satellite receiver
as the source for a VCR, so you would want the
Channel Up/Down Buttons

Y to transmit com-

mands to the cable box even though the other button
commands are programmed to operate the VCR.

To program the remote for channel punch-through,
follow these steps. This example will show how to
program channel punch-through so that the com-
mands programmed for Channel Up/Down for the
VID 3/Cable device will be transmitted when the
VID 1/VCR device has been selected as the
current device.

1. Press and hold the Program Button

O for

about three seconds while the message shown
in Figure 24 appears in the remote’s LCD
Information Display

2. Release the button

when the red light under the Set Button q
appears.

2. The remote’s MAIN MENU message (Fig. 25),

will appear in the LCD display and the Set Button
q will remain illuminated in red. Press the

/

¤

Navigation Button o until PUNCH-

THROUGH appears on the bottom line of the
LCD screen, as shown in Figure 58. Press the
Set Button q to enter the main punch-through
menu branch.

3. At the next menu screen, press the

/

¤

Navigation Button o until CHANNEL
appears on the bottom line of the LCD screen,
as shown in Figure 64. Press the Set Button
q to begin programming the remote for
Channel punch-through.

Figure 64

4. The next display screen (Figure 65) is where you

select the device that will receive the punch-
through commands. In our example, that is the
VID 2/TV button, as that is where we want the
cable box’s channel controls to be active. Press

the

/

¤

Navigation Button o until the

name of the base device appears and then press
the Set Button q.

Figure 65

5. At the next display screen (Figure 66), you will

select the device whose Channel Up/Down com-
mands will be used. Press the

/

¤

Navigation

Button o until the desired device name
appears to the right of the device in use. In
our example, that is the cable box. When the
desired combination of devices appears, press
the Set Button q.

Figure 66

6. When the Set button is pressed, the display will

change to show you that the new combination
of control commands is being saved to the unit’s
memory, as shown in Figure 67. The word
SAVED will flash four times and then the remote
will return to normal operation.

Figure 67

7. Once the punch-through is programmed, the

Channel Up/Down Buttons of the second
device named will be used when those buttons
Y are pressed while the master device is
in use.

Returning the Channel Control Settings to
Default Operation
If you wish to remove the Channel Punch-Through
so that the commands for Channel Up/Down are
returned to the factory default setting, follow the steps
shown above, except that in Steps 4 and 5, select
the same device for both the DEVICE IN USE on
the left side of the bottom line and the PUNCH-
THROUGH device. In the example used, the display
to return the remote to default settings will appear as
shown in Figure 68.

Figure 68

Transport Punch-Through
The Play

Z, Stop J, Fast Forward/Reverse

I, Pause J, Record J and Skip Up/Down
K Transport Controls are set at the factory to oper-
ate your DVD player, or the controls of a specific
device such as a VCR or CD player when they are
selected. However, by using the Transport Punch-
Through feature you may program these controls to

transmit the commands for a different device. For
example, you may wish to operate the transport of a
second VCR connected to the VID 2/TV input, as
shown in the following example.

1. Press and hold the Program Button

O for

about three seconds while the message shown
in Figure 24 appears in the remote’s LCD
Information Display

2. Release the button

when the light under the Set Button q
turns red.

2. The remote’s MAIN MENU message (Fig. 25),

will appear in the LCD display and the Set Button
q will remain illuminated in red. Press the

/

¤

Navigation Button o until PUNCH-

THROUGH appears on the bottom line of the
LCD screen, as shown in Figure 53. Press the
Set Button q to enter the main punch-through
menu branch.

3. At the next menu screen, press the

/

¤

Navigation Button o until TRANSPORT
appears on the bottom line of the LCD screen, as
shown in Figure 69. Press the Set Button q
to begin programming the remote for transport
punch-through.

Figure 69

4. The next display screen (Figure 70) selects the

device that will receive the punch-through com-
mands. In our example, that is the TV button, as
that is where we want the VCR’s transport controls
to be active. Press the

/

¤

Navigation Button

o until the name of the base device appears
and then press the Set Button q.

Figure 70

5. At the next display screen (Figure 71), select the

device whose transport commands will be used.
Press the

/

¤

Navigation Button o until the

desired device name appears to the right of the
device in use. In our example, that is the VCR.
When the desired combination of devices
appears, press the Set Button q.

Figure 71

6. When the Set button is pressed, the display will

change to show you that the new combination of
control commands is being saved to the unit’s
memory, as shown in Figure 72. The word
SAVED will flash four times and then the remote
will return to normal operation.

P U N C H - T H R O U G H
T V

< - V C R

D E V I C E I N U S E
T V

P U N C H - T H R O U G H
T R A N S P O R T

P U N C H - T H R O U G H
V C R

< - V C R

V C R

< - C B L [ C H A N ]

S A V E D

P U N C H - T H R O U G H
V C R

< - C B L

D E V I C E I N U S E
V C R

P U N C H - T H R O U G H
C H A N N E L

P U N C H - T H R O U G H
T V

< - T V
