AVR 435 AUDIO/VIDEO RECEIVER
3 Introduction
4 Important Safety Information
4 Unpacking
5 Front-Panel Controls
8 Rear-Panel Connections
11 Main Remote Control Functions
15 Zone II Remote Control Functions
16 Installation and Connections
19 System Configuration
19 Speaker Placement
19 System Setup
20 Input Setup
21 Audio Setup
22 Surround Setup
23 Using EzSet/EQ
26 Manual Setup
26 Speaker Setup
28 Speaker Crossover Setting
28 Delay Settings
29 Output Level Adjustment
32 Operation
32 Basic Operation
32 Source Selection
32 Volume and Tone Control
33 Surround Mode Selection
33 Digital Audio Playback
34 Surround Mode Chart
37 Tuner Operation
37 Recording
38 Output Level Trim Adjustment
38 Dim Function
39 Advanced Features
39 Front-Panel Display Fade
39 Display Brightness
39 Turn-On Volume Level
39 Semi-OSD Settings
40 Full-OSD Time-Out Adjustment
40 Digital Auto Poll Settings
41 Multiroom Operation
41 Multiroom Setup
41 Surround Channel Amplifier Assignment
42 Multiroom Operation
43 Configuring the Remote
43 Preprogrammed Code Entry
44 Automatic Code Entry
44 Learning Commands
45 Learning Codes for an Input Selector
46 Changing Devices
46 Macro Programming
48 Punch-Through Configuration
50 Renaming
51 Resetting the Remote
52 Device Priority Timing
52 Backlight Options
54 Troubleshooting Guide
54 Processor Reset
55 Technical Specifications
56 Index
See trademark acknowledgements on page 55.
2 TABLE OF CONTENTS
Typographical Conventions
In order to help you use this manual with the remote control, front-panel controls and rear-panel connections,
certain conventions have been used.
EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel
connection jack
EXAMPLE – (OCR type) indicates a message that is visible on-screen or on the front-panel
information display
EXAMPLE – (Synchro type) indicates a message that is displayed on the remote control’s LCD screen
1 – (number in a square) indicates a specific front-panel control
A – (letter in a square) indicates a front-panel control that is normally concealed behind the drop-down door
¡ – (number in a circle) indicates a rear-panel connection
a – (number in an oval) indicates a button or indicator on the remote
å – (letter in an oval) indicates a button on the Zone II remote
The appearance of the text or cursor for your receiver’s on-screen menus may vary slightly from the
illustrations in this manual. Whether the text appears in all uppercase or upper- and lowercase characters,
performance and operation remain the same.
For Canadian model
Modèle pour les Canadien
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
Sur les modèles dont la fiche est polarisee:
ATTENTION: Pour éviter les chocs électriques, introduire
la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu’au fond.
This class B digital apparatus complies with Canadian
ICES-003.
For models having a power cord with a polarized plug:
CAUTION: To prevent electric shock, match wide blade
of plug to wide slot, fully insert.
AVR 435 (SW II) OM 11/18/05 9:20 AM Page 2
