Havis-Shields Kwik-Kit KK-120-05 User Manual
Page 9

KK-XXX-05_INST_8-07
9
VERY IMPORTANT:
Be sure that all Auxiliary lighting, video systems, Kwik kit options, and
wiring are complete. Access is severely limited after kit is installed.
For neatness of wiring, route all
cables down driver-side “B” pillar.
If going under hood for power to
console, drill hole at location above.
1 ½” Hole
“B” Pillar
If optional Power Vent(s)
Notch trim
for wiring
(KK-PVENT) was ordered, see
those instructions at this time for
necessary prep work that must be
done prior to installing Kwik Kit
If optional rear load light(s)
(KK-RLL) was ordered, install at
this time.
See KK-RLL install instructions
Run all wiring for dome lights, power
vents, video system, HVAC, etc. at
this time. Tie to existing OEM harness
At this time go to the KK- (x)-VAK
install instructions. This must be
installed prior to Kwik Kit.
Be sure to tape harnesses to roof in
approximate locations that
accessories are being installed in
Kwik kit. This will vary between
the different model kits.
