INSTALL INSTRUCTIONS
C-VS-0812-CHGR & C-VS-0812-CHGR-1
20” VEHICLE SPECIFIC LOW PROFILE CONSOLE
2006-2007 DODGE CHARGER and MAGNUM
2008 DODGE CHARGER and MAGNUM
TOOLS REQUIRED:
Ratcheting wrench
Sockets - 7/16”
Combo wrench set
Screwdriver set
T-20 torx bit
HARDWARE:
ITEM#
QTY DESCRIPTION PART #
1 1 8” console housing CM000672
2 1 Support bracket for stout console CM001595
3 1 12” Low profile console (housing only) C-SM-1200-H
4 1 Frame support bracket CM001593
5 1 YAW sensor cover panel CM001638
6 1 Rear floor filler panel CM001642
7a 1 Driver side wire panel - 2006 – 07 Charger CM001598-D
7b 1 Driver side trim panel - 2008 Charger CM002165
8a 1 Passenger side wire panel - 2006 – 07 Charger CM001598-P
8b 1 Passenger side trim panels - 2008 Charger CM002164
9 2 “L” bracket mounting leg C-B41
10 1 Extension floor plate CM93712
8 ¼-20 Hex nut GSM30005
8 ¼-20 x ¾” Hex bolt GSM33001
8 ¼-20 Serrated nut GSM30023
6 10-32 x ½” Phillips machine screw GSM33118
4 10-32 Keps nut GSM30028
2 #10 Flat washer GSM31003
2 Torx hardware kits C-HK-1
1 Mounting hardware kit C-HK
