INSTALL INSTRUCTIONS KK-100-05 & KK-120-05
KWIK-KIT PRISONER TRANSPORT INSERT
FORD and CHEVY VAN PRISONER TRANSPORT
TOOLS REQUIRED:
¼” & 3/8” Ratcheting Wrenches
¼” & 3/8”Air Ratchets (recommended)
3/8” Impact Guns (recommended)
¼” & 3/8” Standard Socket Sets
Powered Drill
Powered Screwdriver (recommended)
Drill Bit Set
Tape Measure
Screwdriver Set
Awe or Scribe
Pry-bar
Wire Crimping tool
Wire Stripping tool
Wire Cutter
Table/Circular Saw (if necessary)
Utility knife
Caulking gun
HARDWARE - 60” or 80” COMPARTMENT: Some hardware not used in all application:
QTY DESCRIPTION
PART # USED FOR:
80 ¼” Serrated nut GSM30023
60 ¼” x ¾” Carriage bolt GSM32000
50 #10 x 1” Phillips pan head sheet metal screw GSM33196 Floor/wall to ceiling
8 #8 x 3/8” Phillips flat head screw GSM33179 Vent plates/dome lights
32 ¼” x ¾” Phillips flat head machine screw GSM33078 Wall/Bench extension
25 ¼” x ¾” Hex head bolt GSM33001 3
rd
divider, 3
rd
ceiling
25 ¼” Flat washer GSM31005 3
rd
divider, 3
rd
ceiling
15 ½” Flat washer GSM31009 Grab straps/seat belts
15 ½” Lock washer GSM31030 Grab straps/seat belts
15 ½” x 1 ¼” Socket button head bolt GSM33310 Grab straps/seat belts
4 3/8” x 2” Hex head bolt GSM33032-1 Bulkheads
4 3/8” Hex nut GSM30008 Bulkheads
4 3/8” Lock washer GSM31028 Bulkheads
4 3/8” x 2” Fender washer GSM31022 Bulkheads
2 White Silicone tube PRM97343 Seams & Gaps
4 Lock key PRM97660-1 Doors
4 Vent block off plate KKM0403-004 Ceiling (vent adapter kit)
2 A/C vent plate KKM0403-001 Ceiling (vent adapter kit)
2 Dome light KK-DOME-2 Ceiling
HARDWARE - 40” COMPARTMENT:
QTY DESCRIPTION
PART # USED FOR:
90 ¼” x ¾” Carriage bolt GSM32000
90 ¼” Serrated nut GSM30023
