INSTALLATION INSTRUCTIONS KK-K9-C13-K-32
32” K9 TRANSPORTATION SYSTEM
2000-2009 CHEVROLET SUBURBAN /GMC YUKON
TOOLS REQUIRED:
Power drill
Drill bit set
Standard & metric socket sets
Phillips screwdriver
Open-end wrench set
Wire cutters / Crimping tool
Ratcheting wrench
HARDWARE:
QTY DESCRIPTION PART
#
20
¼-20 x ½” Stainless Carriage Bolts
GSM32022
30
¼-20 x ¾” Stainless Carriage Bolts
GSM32024
50
¼-20 Hex Flange Serrated Nuts Zinc
GSM30023
6
¼” x 1” Hex Head Lag Bolt
GSM33060
22
#12 x ¾” Stainless Sheet Metal Screws
GSM34177
24
#10 x ¾” Sheet Metal Screws Stainless
GSM34170
12
#10 x ½” Sheet Metal Screws Stainless
GSM34169
10
10-32 x ¾” Machine Screw Screws Stainless
GSM34098
6
#10 x ¾” Sheet Metal Screws Zinc
GSM33195
1
Tube Silver Caulk
PRM97343
1
32” x 45” x ½” Rubber Mat
KNM01029
Always
!
¾ Read all instructions before installing any Havis-Shields Equipment Corp products.
¾ Disconnect the vehicle battery. Removing seat bolts on some vehicles may give the vehicles
computer a false reading, causing a warning light on the instrument cluster. This requires the
vehicles’ computer to be reset with a vehicle diagnostics tool.
¾ Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾ Use only hardware provided with install kit.
¾ For product support, visit the Install Instructions Section of our website at
524-9900 and ask for technical support.
SUB ASSEMBLY:
• Mount dome light to ceiling and attach wire
• Remove rear seats and door panels.
• Remove trim panels around the rear door opening to minimize damage while sliding main
housing assembly into the vehicle.
• Attach rear housing extension plate to K9 floor using ¼” x ¾” Carriage bolts and serrated
nuts. The carriage bolt will go up from the bottom. It may be necessary to drill holes to
accommodate the extension plate due to the various models.
