Fuel System Installation (with S/N prior to 07102604)
NOTES:
1. Torque to 20 ft-lbs.
2. See “FasTraks with Honda engines” on page 9-4 for Honda fuel line
routing. See “FasTraks with Kawasaki engines” on page 9-6 for
Kawasaki fuel line routing. See “FasTraks with Kohler Engines” on
page 9-11 for Kohler fuel line routing.
3. Fuel line from left side fuel tank to be routed through grommet and tied
to rear seat support with Item 12.
4. For mowers with serial numbers prior to 07062321, use the following
fuel line lengths:
5. Used on mowers with serial numbers prior to 07062321.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 779306 779306 2 3.5" FUEL CAP
2 600963 600963 1 RIGHT SIDE FUEL TANK
3 600964 600964 1 LEFT SIDE FUEL TANK
4 000323 000323 6 CLIP
5 712919 712919 8 FW .406 X 1.00 X .12 HRD ZNYC
6 055822 055822 8 CS .375-16X .750 HX G5
7 706531 706531 2 GM 1.12 X 1.75 X 1.37 X .12
7 047456 047456 2 GM .687 X 1.312 X 1.00 X .12
8 745059 745059 1 3-WAY FUEL VALVE
9 015818 015818 1 FUEL LINE (25.3" LONG)
10 015818 015818 1 FUEL LINE 8.3" LONG)
11 015818 015818 1 FUEL LINE (36.0" LONG) (HONDA ONLY)
11 015818 015818 1 FUEL LINE (13.0" LONG) (KAWASAKI & KOHLER)
12 000331 000331 3 WIRE TIE SMALL/SHORT
INDEX NO.
SERVICE PART
NO.
DESCRIPTION
9 015818 FUEL LINE (27.3" LONG)
10 015818 FUEL LINE (27.3" LONG)
