Hustler Turf 108277 - Manual (Page 17)

108277 10/08 3-5
Deck Lift Assembly
NOTES:
1. Apply grease to zerks.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 348318 348318 1 STOP HANDLE
2 348284 348284 1 HEIGHT ADJUSTMENT STOP
3 784488 784488 1 DECK LIFT INDICATOR
4 781294 781294 7 E CLIP 1.00 X.625 X.05
5 601681 601681 6 FW .812X1.50X.120 ZNYC
6 704643 704643 8 NT .437-14 HX FLG ZNYC
7 782995 782995 2 DECK LIFT SPRING
8 055749 055749 3 CS .437-14 X 1.75 HX G5
9 781831 781831 1 CS .437-14 X 1.75 FULTH
10 360131 018846 4 DECK LIFT CHAIN (3 LINKS)
11 756270 756270 1 CS .312-18 X 1.50 FLTHR
12 348458 348458 1 DECK LEVELER YOKE
13 781229 781229 1 CE .750 X 2.25 X 1.75 HEADLESS
14 767962 767962 2 FW .406 X .812 X .060 SAE
15 015495 015495 4 STRAIGHT GREASE FITTING 1
