108277 10/08 4-15
Fuel System Installation (with S/N higher than 07102604)
NOTES:
1. Torque to 20 ft-lbs.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 779306 779306 2 3.5" FUEL CAP
2 601320 601320 1 RIGHT SIDE FUEL TANK
3 601321 601321 1 LEFT SIDE FUEL TANK
4 000323 000323 6 CLIP
5 712919 712919 8 FW .406 X 1.00 X .12 HRD ZNYC
6 055822 055822 8 CS .375-16X .750 HX G5
7 745059 745059 1 3-WAY FUEL VALVE
8 015818 015818 1 FUEL LINE (24.00" LONG)
9 015818 015818 1 FUEL LINE 11.00" LONG)
10 015818 015818 1 FUEL LINE (36.0" LONG) (HONDA ONLY)
10 015818 015818 1 FUEL LINE (13.0" LONG) (KAWASAKI)
10 015818 015818 1 FUEL LINE (11.0" LONG) (KOHLER)
11 000331 000331 1 WIRE TIE SMALL/SHORT
12 034280 034280 2 CS .312-18X .750 HX G5
13 768523 768523 4 FW .343X.687X.051/.080H
14 000398 000398 2 CLAMP
15 034272 034272 2 NT .312-18 HX G5 ZNYC
