108277 10/08 3-3
Battery Installation
NOTES:
1. When performing service on mower, disconnect battery ground cable
and do not reconnect to battery until engine is ready to be started. See
Owners Manual.
2. Battery is not installed in export models.
3. Used on mowers using Kohler engines with serial numbers prior to
07080126. Also used on mowers using Kawasaki engines with serial
numbers prior to 070626321.
4. Used on mowers using Kawasaki engines with serial numbers
070626321 and higher.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 714618 714618 2 CS .312-18 X 4.00 HX G5
2 768523 768523 2 FW .343 X .687 X .051/.080 HD
3 348417 348417 1 BATTERY CLAMP STRAP
4 601062 601062 1 POSITIVE BATTERY CABLE (HONDA)
4 601312 601312 1 POSITIVE BATTERY CABLE (KAWASAKI & KOHLER ENGINES)
5 601063 601063 1 NEGATIVE BATTERY CABLE
6 024927 024927 2 NT .250-20 HX GR.5 ZNYC
7 029868 029868 4 LW .250 INT-EXT TOOTH ZNYC
8 055939 055939 2 CS .250-20 X .750 HX G5
9 771428 771428 1 RED BATTERY CABLE BOOT
10 740696 740696 1 BATTERY VU1LH-8
11 601069 601069 2 CN.312-18 X.200 MAX THK
12 794644 794644 2 GM 1.50 X 2.12 X 1.75
13 000331 000331 1 WIRE TIE SMALL/SHORT
3
4
1 2
