Hustler Turf 108277 - Manual (Page 29)

108277 10/08 4-5
Kawasaki 19 & 21 HP Engine Installation
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601082 601082 1 21HP KAWASAKI ENGINE (USED ON 928291)
2 601081 601081 1 19HP KAWASAKI ENGINE (USED ON 928275)
3 058776 058776 4 NT .312-18 HX ZNYC NL
4 768523 768523 11 FW .343 X .687 X .051/.080 HD
5 050161 050161 4 CS .312-18 X 1.75 HX G5
6 784918 784918 1 RUBBER BUMPER
7 000331 000331 1 WIRE TIE SMALL/SHORT
8 799429 799429 1 4.5 OD A SEC PULLEY
9 712372 712372 1 KEY 1/4 SQ X 0.66 LG
10 791251 N/A 1 CLUTCH PIGTAIL HARNESS
11 784835 784835 1 CLUTCH
12 763417 763417 1 FW .454 X 1.50 X .250
13 785048 785048 1 CS .437-20 X 3.00 HX G5 ZNYC
14 029876 029876 1 LW .312 INT-EXT TOOTH ZNYC
15 796524 796524 1 OIL DRAIN VALVE M20 X 2.5
16 601341 601341 1 FASTRAK KAWASAKI WIRE HARNESS
16 600999 N/A 1 FASTRAK KAWASAKI WIRE HARNESS
17 024927 024927 5 NT .250-20 HX GR.5 ZNYC
17 044818 N/A 2 CN ZN TIN-C7343-1420
17 601118 N/A 2 CN .250-20 X .19 MAX THICK
18 768515 768515 11 FW .281 X .625 X .051/.080 HD
19 601062 601062 1 RED BATTERY CABLE (17")
19 792762 N/A 1 RED BATTERY CABLE (9")
20 601319 771428 2 RED BATTERY CABLE BOOT
20 771428 N/A 1 RED BATTERY CABLE BOOT
21 044255 044255 1 NT #10-32 HX ZN
22 055939 055939 2 CS .250-20X .750 HX G5
22 064329 N/A 2 CS .250-20 X .625 HX G5
23 109338 109338 1 HEATSHIELD, FST KAW675CC (21HP ONLY)
24 601429 601429 1 UBOLT .250-20X 1.125 DIA (21 HP ONLY)
601429 601429 2 UBOLT .250-20X 1.125 DIA (19 HP ONLY)
25 601452 601452 1 UBOLT .250-20 X 1.250 ID (21HP ONLY)
26 030817 030817 1 STARTER SOLENOID
27 780841 N/A 2 MUFFLER GASKET
28 785378 785378 1 1.50" MUFFLER CLAMP
29 017004 N/A 4 LW .312 MED SPRING ZNYC
30 782664 N/A 4 NT M8-1.25 HX STAINLESS
31 108288 108288 1 21 KAW FASTRAK HEAT SHIELD
32 034272 034272 2 NT .312-18 HX G5 ZNYC
33 016253 016253 2 CB .312-18 X .75 FUL ZNYC
34 601002 601002 1 FASTRAK HORIZONTAL MUFFLER
35 601004 601004 1 EXHAUST MANIFOLD FASTRAK 21 HP
36 601021 601021 1 EXHAUST MANIFOLD FASTRAK 19 HP
37 043570 043570 1 CLIP - HOSE - SINGLE(FS)
38 792796 792796 1 SC M 6-1.0X15 HX FL STP (19 HP ONLY)
39 109339 109339 1 HEATSHIELD, FST KAW585CC (19 HP ONLY)
40 024927 N/A 4 NT .250-20 HX GR.5 ZNYC
104786 104786 1 OIL DRAIN HOSE (NOT SHOWN)
41 108969 108969 1 HEAT SHIELD
