108277 10/08 4-3
Honda 18 & 20 HP Engine Installation
NOTES:
1. Part of Item 28 (600998 FasTrak wire harness).
2. Two wires.
3. Connected to Item 28 (600998 FasTrak wire harness).
4. Torque to 45-48 ft-lb.
5. Engine oil capacity: See engine manual.
6. Engine speed; High speed - 3450 ±50 RPM .
7. Nuts supplied with item 33 (U-Bolts).
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 784611 784611 1 HONDA 18HP ENGINE
784629 784629 1 HONDA 20HP ENGINE
2 601002 601002 1 HORIZONTAL MUFFLER FST
3 601003 601003 1 FASTRAK MUFFLER MANIFOLD
4 785378 785378 1 MUFFLER CLAMP
5 785543 N/A 2 HONDA (20) MUFFLER GASKET
6 017004 N/A 4 LW .312 MED SPRING ZNYC
7 782664 N/A 4 NT M8-1.25 HX STAINLESS
8 016253 016253 2 CB .312-18X .750 FUL ZN
9 768523 768523 10 FW .343X.687X.051/.080H
10 034272 034272 2 NT .312-18 HX G5 ZNYC
11 787689 787689 1 OIL DRAIN VALVE M14X
12 050161 050161 6 CS .312-18X1.750 HX G5
13 043570 043570 2 CLIP HOSE SINGLE(FS)
14 785477 N/A 1 HONDA 20 AMP RECTIFIER
15 768515 768515 6 FW .281X.625X.051/.080H
16 056077 056077 2 CS .250-20X1.000 HX G5
17 601118 601118 2 CN .250-20 X .19 MAX THK
18 712372 712372 1 KEY 1/4 SQ X 0.66 LG
19 799429 799429 1 PULLEY A SEC 4.5 OD
20 784835 784835 1 FASTRAK CLUTCH
21 763417 763417 1 FW .454X1.50X.250
22 785048 785048 1 CS .437-20X3.00 HX G5 Z
23 784918 784918 1 RUBBER BUMPER
24 791251 N/A 1 CLUTCH PIGTAIL HARNESS
25 000331 000331 1 SMALL/SHORT WIRE TIE
26 070664 070664 4 FW .344X .750X.06 ZNYC
27 058776 058776 6 NT .312-18 HXZY NL
28 600998 600998 1 WIRE HARNESS FASTRAK
29 601063 N/A 1 BATTERY CABLE NEGATIVE
30 029876 029876 1 LW .312 INT-EXT TOOTH Z
31 601062 N/A 1 BATTERY CABLE POSITIVE
32 109340 109340 1 HEATSHIELD, FST HON614CC
33 601429 601429 2 UBOLT .250-20X 1.125 DIA
34 024927 N/A 4 NT .250-20 HX GR.5 ZNYC
35 108969 108969 1 MUFFLER HEAT SHIELD
104786 104786 1 OIL DRAIN HOSE (NOT SHOWN)
