Hustler Turf 108277 - Manual (Page 33)

108277 10/08 4-9
Kohler 19 HP Engine Installation
NOTES:
1. Part of Item 2 ( 601000/601342 Kohler Wire Harness).
2. Torque to 45-48 ft-lb
3. Torque to 30-35 ft-lbs. Do not reuse factory installed screw when
performing service to mower requiring removal of engine, replace with
3/8-16 x 1.0 long grade 5 cap screw.
4. Engine oil capacity: See engine owner’s manual.
5. Engine speed; High Idle—3450±50 rpm, Low idle—1900±100 rpm.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601067 601067 1 19 HP KOHLER COURAGE ENGINE
2 601342 601342 1 KOHLER WIRE HARNESS
2 601000 601000 1 KOHLER WIRE HARNESS
3 058776 058776 1 NT .312-18 HX NL ZNYC
4 768523 768523 4 FW .343 X .687 X .051/.080 HD ZNYC
5 029876 029876 1 LW .312 INT-EXT TOOTH ZNYC
6 024927 024927 4 NT .250-20 HX GR.5 ZNYC
7 768515 768515 10 FW .281 X .625 X .051/.080 HD ZNYC
8 044255 044255 1 NT #10-32 HX ZN
9 601319 601319 2 RED BATTERY CABLE BOOT
9 771428 N/A 1 RED BATTERY CABLE BOOT
10 030817 030817 1 STARTER SOLENOID
11 601312 601312 1 4" RED BATTERY CABLE
11 792762 N/A 1 9" RED BATTERY CABLE
12 055939 055939 2 CS .250-20X .750 HX G5
13 038828 038828 1 CS .312-18 X 2.25 HX G5 ZNYC
14 780841 N/A 1 EXHAUST GASKET
15 601005 601005 1 KOHLER EXHAUST MANIFOLD
16 601002 601002 1 FASTRAK HORIZONTAL MUFFLER
17 016253 016253 2 CB .312-18 X .750 FUL ZN
18 785378 785378 1 1.50" MUFFLER CLAMP
19 034272 034272 2 NT .312-18 HX G5 ZNYC
20 796516 796516 1 3/8-18 OIL DRAIN VALVE
21 036244 N/A 3 CS .375-16X1.000 HX G5
22 784918 784918 1 RUBBER BUMPER
23 799429 799429 1 A SEC, 4.5 OD PULLEY
24 712372 712372 1 1/4 SQ X 0.66 LG KEY
25 784835 784835 1 FASTRAK CLUTCH
26 791251 N/A 1 CLUTCH PIGTAIL HARNESS
27 763417 763417 1 FW .454X1.50X.250
28 785048 785048 1 CS .437-20 X 3.00 HX G5 Z
29 000331 000331 1 WIRE TIE SMALL/SHORT
30 108969 108969 1 MUFFLER HEAT SHIELD
31 109252 109252 1 HEATSHIELD, FST KOH COURAGE
32 601429 601429 2 UBOLT .250-20X 1.125 DIA
33 024927 N/A 4 NT .250-20 HX GR.5 ZNYC
34 104786 104786 1 OIL DRAIN HOSE (NOT SHOWN)
8
8
9
8
3
6
11
