Page 20
3-8
108277 10/08
Steering Sub-Assembly
NOTES:
1. Includes Item 1 (781260 Steering Bar Grip).
ITEM NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY.
DESCRIPTION
1
781260
N/A
2
STEERING BAR GRIP
2
360487
360487
2
STEERING BAR
3
767954
767954
12
FW .406 X .812 X .060 SAE HD ZN
4
705178
705178
4
CS .375-16X1.750 HX G5
5
086660
086660
6
NT .375-16 HXZY NL
6
107843
107843
1
STEERING ARM W/A LH (SHOWN)
107842
107842
1
STEERING ARM W/A RH
7
768523
768523
4
FW .343X .687 X .051/.080 HD ZN/YL
8
600991
600991
2
SHORT BRAKE LINK ROD
9
023655
023655
2
NT .312-24 HXZY NL
10
107848
107848
1
STEER PIVOT W/A LH (SHOWN)
107847
107847
1
STEER PIVOT W/A RH
11
770867
770867
4
IGUS BUSHING
12
705178
705178
2
CS .375-16X1.750 HX G5
2
3
7
3
8
10
4
11
3
12
3
5
5
11
1
3
9
3
7
3
CONNECTS TO
PARK BRAKE
LINKAGE
6
1
