2
[b] KMD-410MWH (water-cooled)
AC SUPPLY VOLTAGE 115/60/1 㩷
AMPERAGE 6.5 A (5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day (kg/day) 70 *440 (200) 423 (192) 392 (178)
Reference without *marks 80 427 (194) 401 (182) 364 (165)
90 423 (192) *382 (173) 347 (157)
100 414 (188) 373 (169) 315 (143)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 8.2 lbs. (3.7 kg) 416 pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 680(4.3) 670(3.7)
WATER gal./24HR (gal./100 lbs.) 89(23.2) 120(27.2)
WATER COOLED CONDENSER 552(145) 267(61)
gal./24HR (gal./100 lbs.) 㩷 㩷
EXTERIOR DIMENSIONS (WxDxH) 22-1/4" x 24-1/8" x 24" (565 x 613 x 610 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 128 lbs. (58 kg), Shipping 163 lbs. (74 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT Cond. Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT Cond. Outlet 1/2" FPT
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled, Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Level Switch with Delay
COMPRESSOR Hermetic, Model NT6217GKV
CONDENSER Water-Cooled, Tube in tube type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R-404A, 14.1 oz. (400g)
DESIGN PRESSURE High 427PSIG, Low 206PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out (Internal)
COMPRESSOR PROTECTION Auto-reset Overload Protector (Internal)
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES - SUPPLIED N/A
- REQUIRED Ice Dispenser or Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 104 - 127 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
We reserve the right to make changes in specifications and design without prior notice.
