5) Refit the removed parts in the reverse order of the removal procedure.

Note: After replacing the components inside the control box, connect and tie the wires

properly in their correct position. Especially make sure that the harness does not
press the push buttons on the control board.

Control Box Cover

Control Box

Screw

Screws

Controller Board

Control Switch

Service Switch

Fuse
Fuse Holder

Starter

Transformer

Capacitor for Pump Motor

Magnetic Contactor

Push Buttons

Run Capacitor

Start Capacitor

Noise Suppression Capacitor
