1
AC SUPPLY VOLTAGE 115/60/1 㩷
AMPERAGE 8.0 A (5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day (kg/day) 70 *415 (188) 388 (176) 354 (160)
Reference without *marks 80 395 (179) 353 (160) 320 (145)
90 388 (176) *324 (147) 289 (131)
100 382 (173) 316 (143) 257 (117)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 8.5 lbs. (3.9 kg) 416 pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 780(5.8) 710(4.1)
WATER gal./24HR (gal./100 lbs.) 73(22.6) 148(35.7)
EXTERIOR DIMENSIONS (WxDxH) 22-1/4" x 24-1/8" x 24" (565 x 613 x 610 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 126 lbs. (57 kg), Shipping 161 lbs. (73 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled, Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Level Switch with Delay
COMPRESSOR Hermetic, Model NT6217GKV
CONDENSER Air-Cooled, Fin and tube type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R-404A, 1 lb. 2.3 oz. (520g)
DESIGN PRESSURE High 467PSIG, Low 206PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out (Internal)
COMPRESSOR PROTECTION Auto-reset Overload Protector (Internal)
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES - SUPPLIED N/A
- REQUIRED Ice Dispenser or Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 104 - 127 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113PSIG
We reserve the right to make changes in specifications and design without prior notice.
I. SPECIFICATIONS
1. SPECIFICATIONS
[a] KMD-410MAH (air-cooled)
