Page 25
Chapter 1: Getting Started
25
Front, Side, and Bottom of the
Camera
# Name
Description
1 Flash
Provides additional light to improve
picture-taking.
2
Self-Timer
light
Blinks red when the
Self-Timer
is activated.
3 Microphone
Records sound (audio and video).
4
USB
connector
Allows you to connect a USB cable from
the camera to a USB-enabled computer
or printer.
5
Power
adapter connector
Allows you to connect the HP AC power
adapter to the camera to either operate
the camera without a battery, or recharge
the lithium ion rechargeable battery in
the camera.
6
7
8
1
4
5
2 3
