SERVICING YOUR OUTBOARD MOTOR
TILT LOCK LEVER
(each side)
TILT SHAFT THREAD
SHIFT LINK BRACKET/
SHIFT PIVOT/SHIFT ARM/
LINK PIN/PIVOT PLATE/
SLIDE PIVOT/
CLICK SPRING ROLLER
SWIVEL SHAFT
UPPER CYLINDER
PIN/BUSHING
LOWER CYLINDER
BUSHING/COLLAR
MOUNT FRAME
