63
EMERGENCY STARTING
OPERATION
ENGINE COVER
LATCHES
(front/rear)
UNLOCK
BREATHER
TUBE CLAMP (on the
silencer case)
6 mm WASHER 6 25 mm
FLANGE BOLT
CLAMP
CLAMPS
HOOKS
ALTERNATOR
COVER
TAKING CARE OF
UNEXPECTED PROBLEMS
During the warm-up period, check
the oil pressure indicator (p.
),
overheat indicator (p. ), and
cooling system indicator (p. ).
If the indicators show any
abnormal condition, immediately
stop the engine and determine the
cause of the problem. Refer to
on
p. .
If the fast idle button was used to
warm up the engine, gradually
return the control lever to the N
(neutral) position as the engine
warms up.
If the battery is discharged or the
starter motor is inoperative, you can
start the engine manually using the
emergency starter rope supplied with
the motor.
Turn the engine switch key to the
OFF position.
Unlatch and remove the engine
cover.
Release the breather tube from the
four clamps.
Remove 6 25 mm flange bolt
and washer, and then remove the
alternator cover.
Secure the breather tube to the
clamp of the silencer case.
Take care not to lose the bolt and
washer.
39
40
41
119 122
5.
1.
2.
3.
4.
6.
