42
OTHER FEATURES
Water Separator Buzzer
Overrev Limiter Portable Fuel Tank
[optional equipment
(LHT type)]
CONTROLS AND FEATURES
WATER SEPARATOR
FUEL TANK
FUEL HOSE
The water separator buzzer sounds a
rapid, repeating signal when water
has accumulated in the water
separator.
The engine is equipped with an
overrev limiter to prevent the
possibility of mechanical damage
from excessive engine speed.
The overrev limiter may be activated
during operation, limiting engine
speed, if the outboard motor is
trimmed or tilted up excessively, or
when propeller ventilation occurs
during a sharp turn.
If the overrev limiter is activated,
check the trim angle of the outboard
motor.
Check to see if the correct propeller
is installed.
The portable fuel tank has a capacity
of
US gal ( L) and has a fuel
gauge built into the cap.
6.6 25
