29
Top-Mount Type
CONTROLS AND FEATURES
ON
OFF
START
IGNITION
SWITCH
EMERGENCY STOP SWITCH
EMERGENCY STOP
SWITCH CLIP LANYARD
LANYARD
EMERGENCY STOP
SWITCH CLIP
Ignition Switch
Emergency Stop Switch Clip and
Emergency Stop Switch Turning the ignition switch key to the
START position operates the starter
motor. The key automatically returns
to the ON position when released
from the START position.
Turning the ignition switch to the
OFF position stops the engine.
The ignition switch controls the
ignition system and the starter motor.
The ignition switch can be used to
start the engine only when the control
lever is in the N (neutral) position (p.
) and the emergency stop switch
clip is in the emergency stop switch.
61
