2.5 lbf·ft (3.4 N·m , 0.35 kgf·m)
98
SERVICING YOUR OUTBOARD MOTOR
O-RING
WATER
SEPARATOR
BAFFLE
PLATE
BODY
WATER
SEPARATOR
CUP
SUSPENSION
STRAP
FLAT PART ON BACK
OF SUSPENSION
JOINT
Assemble so the flat part of the
suspension and the water separator joint
are parallel to each other.
WATER LEVEL
SENSOR 2P
CONNECTOR POSITIONING
BAND
HARNESS
CLIP
POSITIONING
BAND CLIP C
SCREW (3)
Connect the water level sensor 2P
connector. Install the harness to
clip C and the harness clip.
Align the positioning bands on the
harness with the end of clip C and
the harness clip as shown above.
Reinstall the water separator in the
reverse order of removal.
Assemble so the flat part on the
back of the suspension is parallel
to the water separator joint as
shown below.
Reassemble the water separator
body, baffle plate, O-ring and the
cup.
TIGHTENING TORQUE:
Thoroughly clean the water
separator cup.
Remove the three screws and
separate the water separator cup
from the body. 7.
8.
9.
10.
11.
