25
Panel-Mount Type
CONTROLS AND FEATURES
FAST IDLE LEVER
MAXIMUM FAST IDLE
START
ON
OFF
N (neutral)
LOWEST
POSITION
IGNITION
SWITCH
Ignition Switch
The fast idle lever allows you to
increase the idle speed only when the
control lever is in the N (neutral)
position. Place the fast idle lever in
its lowest position to cancel the fast
idle and return the control lever to
normal operation. The ignition switch controls the
ignition system and the starter motor.
Turning the ignition switch key to the
START position operates the starter
motor. The key automatically returns
to the ON position when released
from the START position.
The ignition switch can be used to
start the engine only when the control
lever is in the N (neutral) position (p.
) and the emergency stop switch
clip is in the emergency stop switch.
Turning the ignition switch to the
OFF position stops the engine.
58
