39
Oil Pressure Indicator
CONTROLS AND FEATURES
(side-mount type)
(panel-mount/top-mount types)
(GREEN)
BUZZER
BUZZER
(GREEN)
(GREEN)
OIL PRESSURE
INDICATOR
(internal buzzer)
LHT Type
LRT and XRT Types When the engine control system
detects a PGM-FI malfunction, the
PGM-FI indicator turns on and the
buzzer sounds at one-second
intervals.
Under normal conditions, when the
ignition key is turned on the
following will occur:
Both the PGM-FI indicator and
ACG indicator will turn on.
The buzzer will beep twice.
The PGM-FI indicator will turn
off shortly after the second beep.
The ACG indicator will turn off
after the engine starts. 1.
2.
3.
4.
