HONDA Outdoor Motor BF90D - Manual (Page 38)

36
Digital Tachometer Tachometer
(optional equipment) INSTRUMENTS
Trim Meter
(optional equipment)
(optional equipment)
CONTROLS AND FEATURES
TACHOMETER
TRIM METER
Digital Tachometer includes the
following functions.
Tachometer
Hour Meter
Trim Meter
Oil Pressure Indicator
Overheat Indicator
ACG Indicator
PGM-FI Indicator
Refer to the Operation Guide
included with the Digital Tachometer
for operation information.
The tachometer shows engine speed
in revolutions per minute.
Refer to the tachometer when using
the throttle and power trim/tilt
controls to achieve the best
performance from the boat. The trim meter indicates the relative
trim angle of the outboard motor.
Refer to the trim meter when using
the power trim/tilt switch to achieve
the best performance from the boat.
08/08/04 18:44:07 31ZY9600_037
