92
Lubrication Points
SERVICING YOUR OUTBOARD MOTOR
THROTTLE ROD/LINK
TILT BRACKET
SWIVEL CASE PROPELLER SHAFT
TILT SHAFT
THRUST RECEIVER
TILLER HANDLE
(LHT type)
THROTTLE ARM/
LINK/PIVOT/PLATE
Apply anticorrosion oil to pivot
surf aces where grease cannot penetrate.
Apply Honda Marine Corrosion Inhibitor (or equivalent) to all areas under the engine cover and any exposed metal
surfaces except the belts.
Lubrication interval:
After the first 20 hours or 1 month, then
every 100 hours or 6 months (refer to
the maintenance schedule on page
).
Apply Honda Marine waterproof grease
to the parts shown below:
81
