Specifications 45
UPS model Load
segment Circuit
breaker Output
receptacles Maximum current
2 x IEC-320-C13 10 A per receptacle
1 x L6-30R Up to full UPS power rating
2 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
R5500 XR INTL 1 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
1 x IEC-309-32A Up to full UPS power rating
2 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
¹ NOTE: The circuit breakers protect the C19 and C13 outlets.
² NOTE: If an extension bar is connected to a C19 receptacle, the maximum current for each
C13 receptacle on the extension bar is 10 A. The total maximum current for the extension bar
is 12 A.
Power protection specifications
UPS model VA Nominal power
rating (W) Nominal
voltage setting
R5500 XR NA/JPN 5000 4500 200/208, 220,
230, 240
R5500 XR INTL 6000 5400 220, 230, 240
5000 4500 200/208
Voltage specifications
Configuration setting (VAC) Available nominal output voltage
(VAC)
200/208 204
220 220
230 230
240 240
