HP R5500 - Manual (Page 44)

Specifications 44
Specifications
UPS physical specifications
Parameter Value
Height 13.03 cm (5.13 in)
Depth 66.04 cm (26 in)
Width 44.15 cm (17.38 in)
Weight 68 kg (150 lb)
ERM physical specifications
Parameter Value
Height 13.03 cm (5.13 in)
Depth 63.83 cm (25.13 in)
Width 44.45 cm (17.50 in)
Weight 75 kg (167 lb)
UPS input specifications
NOTE: An asterisk (*) indicates the default setting.
UPS model Utility voltage
frequency (Hz)
Available settings
utility voltage (VAC)
Dedicated
branch circuit
rating (A)
Line cord
R5500 XR
NA/JPN 50/60 200/208*, 220, 230,
240
30 Nondetachable power
cord with NEMA L6-30
plug
R5500 XR INTL 50/60 200/208, 220, 230*,
240
32 Nondetachable power
cord with 32 A IEC-309
plug
UPS output specifications
UPS model Load
segment
Circuit
breaker
Output
receptacles
Maximum current
R5500 XR NA/JPN 1 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
