Component identification 7
UPS front panel controls
The front panel is shown with the bezel removed.
Item Description Function
1 On button Powers up the UPS (" Starting power to the
load " on page 24 )
2 Standby button Places the UPS in Standby mode (on page
27 )
3 Test/Alarm Reset button • Silences UPS alarms (" Silencing an
audible alarm " on page 30 )
• Tests the LEDs (" Testing the LEDs " on
page 29 )
4 Configure button Places the UPS in Configure mode (on page
28 )
