5
2
Getting
Started
Heat-N-Glo direct vent gas fireplaces are designed to
operate with all combustion air siphoned from outside
of the building and all exhaust gases expelled to the
outside.
The information contained in this Installers Guide,
unless noted otherwise, applies to all models and
gas control systems.
Gas fireplace diagrams, including the dimensions,
are shown in this section.
This gas fireplace and its components are tested
and safe when installed in accordance with this
Installers Guide. Report to your dealer any parts
damaged in shipment, particularly the condition of
the glass. Do not install any unit with damaged,
incomplete, or substitute parts.
NOTE: FOR MODEL 6000TR ONLY:
These fireplaces are shipped from the factory with a
BTU rating of 27,000 BTU’s. The fireplace can be
installed with the vent pipe coming off the top of the
unit or the rear of the unit. If you install the unit with
the vent pipe coming off the top of the unit, you may
run the unit at 31,000 BTU (NG) (30,000 BTU LP),
replace the burner orifice with the orifice included in
the manual bag. DO NOT REPLACE THE ORIFICE
IF YOU ARE USING THE REAR SET OF VENT
COLLARS.
Changing the orifice when venting out the top.
1. Remove the glass door.
2. Using a 1/4” socket, remove the sheetmetal
screws holding the long refractory clip in place.
Remove the logs and refractory as one piece.
3. Remove the protective plastic from the logs.
4. Remove the two sheetmetal screws holding the
burner and remove the burner.
5. Replace the burner orifice with the orifice in-
cluded in the plastic manual bag (#36DMS for
natural gas or #51DMS for propane). Be careful
to hold the brass elbow so you don’t kink the
aluminum tube.
6. Reverse the steps to replace the burner, logs,
refractory, and clip.
The vent system components and trim doors are
shipped in separate packages. The gas logs may
be packaged separately and must be field installed.
Read all of the instructions before starting the
installation. Follow these instructions carefully
during the installation to ensure maximum
safety and benefit. Failure to follow these
instructions will void the owner’s warranty and
may present a fire hazard.
Introducing the
Heat-N-Glo
Gas Fireplaces
Pre-install
Preparation
