43

STANDING PILOT

Figure 41. Burner Flame Patterns

MAKE SURE THE FLAMES

ARE STEADY—NOT

LIFTING OR FLOATING.

Figure 42. Pilot/Ignitor Flame Patterns

DSI IGNITION

NOTE: FLAMES

TOO CLOSE TO

THE CERAMIC

INSULATORS CAN

CAUSE NUISANCE

LOCKOUTS AND

ELECTRODE

FAILURE.

1/4" (6mm)

IGNITOR

3/8” (10mm)

CERAMIC

INSULATOR
