Rear lift arm – Hustler Turf 1500 User Manual
Page 95
114443_1011
9-7
Rear Lift Arm
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
114294
1
STABILIZER ARM, REAR
2
781153
2
BUSHING
3
025296
3
FW .760 X 1.625 X .08 ZNYC
4
601084
1
SB .750 X 2.000 SH.625-11
5
016972
1
NT .625-11 HX G5 ZNYC
6
052837
4
CS .312-18 X 1.500 HX G5
7
712927
7
FW .344 X 1.00 X.12 HRD Z
8
113886
2
REAR REEL LIFT CHAIN
9
034272
4
NT .312-18 HX G5 ZNYC
10
768523
13
FW .343 X .687 X .051/.080H
11
041152
2
NT .312-24 HX ZNYC
12
770867
2
BUSHING
13
602418
1
SINGLE ROD CYLINDER
14
603083
1
NT .750-16 HX G5 ZN JAM
15
754358
2
SB .375 X .375 SH .312-18
16
601507
1
FW .406 X 1.000 X .06 NYLON
17
114302
1
LIFT ARM DOG BONE
18
603308
1
LIFT YOKE
19
765339
1
BUSHING
20
034280
2
CS .312-18 X .750 HX G5
21
602539
2
BUSHING .625 I.D.
22
706143
1
NT .312-18 HX JAM GR5 ZY
23
114281
1
RS REEL LIFT
24
781583
1
BRAKE ROD
25
602397
2
BUSHING, 1.00 I.D.
26
112005
1
RS FRONT LIFT ARM
27
015495
3
GREASE FITTING STRAIGHT
28
054502
6
NT .375-16 HX GRD 5 ZNY
29
767954
10
FW .406 X .812 X .060 SAE
30
114305
1
REAR LIFT SPRING ANCHOR
31
798264
1
FW .406 X 1.50 X .06 ZNYC
32
005132
1
CS .375-16 X 1.12 HX G5 Z
33
601486
1
EB, .375-16 X 3.00 FULL THD
34
601016
1
IDLER SPRING
35
041855
1
SB .625 X 1.250 SH.500-13
NOTES:
