114443_1011

7-25

Hydraulic Reel Lift

INDEX NO.

PART NO.

QTY.

DESCRIPTION

1

602497

1

HOSE ASSY, BLOCK FILTER

2

602502

1

HOSE ASSY, FRONT BLANK

3

602505

1

HOSE ASSY, REAR BLANK

4

603286

1

HOSE ASSY, FRONT ROD

5

603288

1

HOSE ASSY, FRNT BLANK LS

6

603287

1

HOSE ASSY, FRONT ROD LS

7

603198

2

FTG, 4MORB/4FSL STR SWVL

8

602918

2

FITTING, 4MORB/4MSL STR

9

602506

1

HOSE ASSY, REAR ROD

10

602584

1

FTG, 4MORB/4MSL 90

11

602890

1

FTG, 4MORB/4FSL 90 SWL

12

602892

3

FTG, ORIFICE CHECK

13

602893

3

ORIFICE POPPIT

14

603289

1

GM, 2.25ID X 3.0OD X 2.5GD

15

033001

6"

TRIM

16

079186

1

CS .312-18 X 1.250 HX G5

17

712927

1

FW .344 X 1.00 X.12 HRD Z

18

602604

1

HOSE CLAMP, .625

19

060889

2

WIRE TIE, BIG/LONG

NOTES:
