Rear steering fork -10, Rear steering fork – Hustler Turf 1500 User Manual
Page 25
114443_1011
3-11
Rear Steering Fork
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
602726
1
VINYL CAP
2
705954
1
CS .500-13 X 1.250 HX G5 ZN
3
602668
1
FW .531 X 2.5 X .134
4
602425
2
ROLLER BEARING
5
047704
1
CS .625-11 X 3.500 HX G5
6
025296
5
FW .760 X 1.625 X .08 ZNYC
7
015495
1
GREASE FITTING STRAIGHT
8
115157
1
BUSHING, STEER CYLINDER
9
045765
1
FW 1.030 X 1.500 X .134 ZN
10
115839
1
GREASE SHIELD
11
602417
1
STEERING CYLINDER
12
016725
1
CS .750-10 X 2.500 HX ZNY
13
602721
1
ROD END
14
061101
1
NT .750-10 HXZY NL
15
036855
1
NT .750-16 HX ZNYC
16
111976
1
CASTER FORK
17
728030
1
FW .656 X 1.312 X .090 ZNY
18
058768
1
NT .625-11 HXZY NY
19
008193
4
NT .500-13 HX G5 ZNYC
20
767962
8
FW .531 X 1.063 X .090 SAE
21
112138
1
SPINDLE
22
074252
4
CS .500-13 X 1.500 HX G5
23
602526
1
SPINDLE HUB
24
602533
5
WHEEL STUD
25
602527
1
SEAL
26
603410
1
HUB BEARING, RACE KIT (INCLUDES SEAL)
27
602532
1
HUB
28
602529
1
DUST CAP
29
061077
5
LUG NUT
30
602525
1
COTTER PIN
31
602524
1
WASHER
32
602523
1
SHAFT NUT
NOTES:
