Hustler Turf 1500 - Manual (Page 63)

114443_1011 7-7
Hydraulic—Oil Cooler
INDEX NO. PART NO. QTY. DESCRIPTION
1 034280 10 CS .312-18 X .750 HX G5
2 768523 16 FW .343 X .687 X .051/.080H
3 112181 1 SUPPORT ANGLE
4 601069 6 CN .312-18 X .200 MAX THK
5 112174 1 OIL COOLER SHROUD
6 034272 6 NT .312-18 HX G5 ZNYC
7 713198 4' SEAL 3/8 X 3/4
8 602564 1 OIL COOLER
9 033035 3.25' WEATHERSTRIP .12 X .75
10 113561 1 OIL COOLER SCREEN
11 113557 1 FRONT PANEL OIL COOLER
12 079210 2 FW .344 X 1.00 X .06 ZNYC
13 602620 1 GROMMET
14 602619 2 BUSHING
15 112618 2 SPACER TUBE
16 052837 2 CS .312-18 X 1.500 HX G5
17 781658 1 FTG, -8 MORB/HEX PLUG
NOTES:
