114443_1011

7-11

Hydraulic Valve Block

INDEX NO.

PART NO.

QTY.

DESCRIPTION

1

064329

4

CS .250-20 X .625 HX G5

2

768515

4

FW .281 X .625 X .051/.080H

3

064014

2

CS .312-18 X .875 HX G5 ZN

4

768523

20

FW .343 X .687 X .051/.080H

5

034280

10

CS .312-18 X .750 HX G5

6

034272

8

NT .312-18 HX G5 ZNYC

7

112460

1

SUPPORT PLATE, VALVE

8

602452

1

VALVE MANIFOLD BLOCK

9

602835

1

SPACER

10

112455

1

CHANNEL, VALVE

11

601069

2

CN .312-18 X .200 MAX THK

12

112088

1

BRACKET, FILTER MOUNT

13

602567

2

FILTER HEAD, 50PSI

14

602568

2

FILTER ELEMENT, 10 MICRON

15

055822

2

CS .375-16 X .750 HX G5

16

767954

2

FW .406 X .812 X .060 SAE

NOTES:
