Drive linkage – Hustler Turf 1500 User Manual
Page 21
114443_1011
3-7
Drive Linkage
INDEX NO.
PART NO.
QTY.
DESCRIPTION
28
551017
1
FWD/REV PEDAL (W/ TREAD)
29
602706
1
STEP TREAD
30
056325
3
CB .250-20 X 1.000 FUL Z
31
706143
2
NT .312-18 HX JAM GR5 ZY
32
722678
2
SB .375 X .62SH .312-18 T
33
781922
2
BALL STUD
34
602667
1
STEERING DAMPER
35
713685
2
FW .312 X .75 X .06 ZNYC
36
114303
1
PIVOT BRACKET
37
765339
3
BUSHING
NOTES:
