Fuel system – Hustler Turf 1500 User Manual
Page 53
114443_1011
6-9
Fuel System
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
602980
2
3.0" CUSHIONED CLAMP
2
767954
2
FW .406 X .812 X .060 SAE
3
055822
5
CS .375-16 X .750 HX G5
4
602982
1
CARBON CANISTER, 9 GAL.
5
000323
6
HOSE CLAMP
6
015818
69"
1/4" FUEL LINE
7
603221
1
FTG, -4BARB / -6BARB STR
8
603224
1
SPRING CLAMP
NOTES:
FUEL & VAPOR LINE LENGTHS
1
28"
TANK TO CANISTER (VAPOR)
2
20"
TANK TO FUEL FILTER (FUEL)
3
21"
CANISTER TO ENGINE (VAPOR)
