Hustler Turf 1500 - Manual (Page 93)

114443_1011 9-5
Front Lift Arm
INDEX NO. PART NO. QTY. DESCRIPTION
39 016527 2 CS .500-13 X 1.00 HX G5 ZN
40 712976 2 FW .531 X 1.375 X .125 ZNY
41 113873 2 CHAIN BRACKET
42 063552 4 CE .310 X 1.87 .150 X 1.73
43 705608 6 CS .250-20 X 2.25 HX G5 Z
44 768515 12 FW .281 X .625 X .051/.080H
45 068551 6 NT .250-20 HXZY NL
46 706549 4 HP .08 0D X 1.19
47 602865 2 .438 X 1.750 LYNCH PIN
48 045765 2 FW 1.030 X 1.500 X .134 ZN
49 601375 2 O-RING, SAE-14
50 112014 2 ROLLING ARM
51 112817 2 FRONT REEL STOP
52 036244 8 CS .375-16 X 1.000 HX G5
53 112772 4 BASKET RETAINER
54 602925 2 REEL SAFETY DECAL
55 551015 2 REEL CARRIER W/ DECAL
56 058776 4 NT .312-18 HXZY NL
NOTES:
2. Right side assembly is shown; left side assembly is similar.
