Traction drive, Orient as shown – Hustler Turf 1500 User Manual
Page 73
114443_1011
7-17
Traction Drive
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
781526
4
FTG, 90°-10 MORB/-8 MORFS
2
602490
1
HOSE ASSY, RIGHT WHEEL
3
602491
1
HOSE ASSY, RIGHT WHEEL
4
602499
1
HOSE ASSY, HST SUPPLY
5
748574
1
FTG, 6 MORB/6 MSL 90
6
602446
2
FTG, TEE 10 MORB/8 MSL
7
602488
2
HOSE ASSY, LEFT WHEEL
8
060889
2
WIRE TIE
NOTES:
1. Orient as shown.
