114443_1011

2-5

Footrest

INDEX NO.

PART NO.

QTY.

DESCRIPTION

1

550986

1

FLOOR PLATE (WITH TREADS & DECALS)

2

602920

1

FWD-REV DECAL

3

112852

1

FOOT PAN STEP TREAD

4

602915

1

PARK BRAKE DECAL

5

603364

1

LEFT STEP TREAD

6

808485

6

RIVET NUT, 5/16-18 THREAD

7

768523

9

FW .343 X .687 X .051/.080H

8

602727

10

CS .312-18 X 1.0 BHSK ZNYC

9

601069

13

CN .312-18 X .200 MAX THK

10

114392

1

FLOOR PLATE EXTENSION

11

550984

1

RS FLOOR COVER (WITH TREAD)

12

112851

2

STEP TREAD, COVER

13

550985

1

LS FLOOR COVER (WITH TREAD)

14

034280

9

CS .312-18 X .750 HX G5

15

033035

21"

WEATHERSTRIP .12 X .75

NOTES:
