Front lift arm – Hustler Turf 1500 User Manual
Page 91
114443_1011
9-3
Front Lift Arm
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
114292
1
RS FRONT STABILIZER
2
114293
1
LS FRONT STABILIZER (NOT SHOWN)
3
601084
2
SB .750 X 2.000 SH.625-11
4
025296
6
FW .760 X 1.625 X .08 ZNYC
5
781153
4
BUSHING
6
016972
2
NT .625-11 HX G5 ZNYC
7
052837
8
CS .312-18 X 1.500 HX G5
8
712927
14
FW .344 X 1.00 X.12 HRD Z
9
113886
4
REEL LIFT CHAIN
10
034272
8
NT .312-18 HX G5 ZNYC
11
768523
26
FW .343 X .687 X .051/.080H
12
041152
4
NT .312-24 HX ZNYC
13
770867
4
BUSHING
14
602418
2
SINGLE ROD CYLINDER
15
603083
2
NT .750-16 HX G5 ZN JAM
16
754358
4
SB .375 X .375 SH .312-18
17
601507
2
FW .406 X 1.000 X .06 NYLON
18
114302
2
LIFT ARM DOG BONE
19
603308
2
LIFT YOKE
20
765339
2
BUSHING
21
034280
4
CS .312-18 X .750 HX G5
22
602539
4
BUSHING .625 I.D.
23
706143
2
NT .312-18 HX JAM GR5 ZY
24
114281
1
RS REEL LIFT
25
114291
1
LS REEL LIFT (NOT SHOWN)
26
781583
2
BRAKE ROD
27
602397
4
BUSHING, 1.00 I.D.
28
112005
1
RS FRONT LIFT ARM
29
112006
1
LS FRONT LIFT ARM (NOT SHOWN)
30
015495
6
GREASE FITTING STRAIGHT
31
054502
12
NT .375-16 HX GRD 5 ZNY
32
767954
20
FW .406 X .812 X .060 SAE
33
112136
1
REEL LIFT SPRING ANCHOR
34
112000
1
LIFT ARM RETAINER
35
601486
2
EB, .375-16 X 3.00 FULL THD
36
005132
2
CS .375-16 X 1.12 HX G5 Z
37
601016
2
IDLER SPRING
38
041855
2
SB .625 X 1.250 SH.500-13
NOTES:
1. Right side assembly is shown; left side assembly is similar.
