Drive linkage, Part of cable – Hustler Turf 1500 User Manual
Page 19
114443_1011
3-5
Drive Linkage
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
602610
1
CABLE, PUSH/PULL 2"STRK
2
036384
1
SPRING 1/4 COIL PL 1.23
3
038828
1
CS .312-18 X 2.250 HX G5
4
112497
1
PIVOT CAM STUD
5
112496
1
CENTERING LEVER
6
603262
1
BUSHING, 1.00 I.D.
7
017616
1
CS .500-13 X 1.750 HX G5
8
602631
1
BEARING
9
718288
5
FW .516 X .875 X .09 ZNYC
10
112493
1
CONTROL LEVER ARM
11
008193
1
NT .500-13 HX G5 ZNYC
12
028035
5
CS M 8-1.25 X 20 HX G8.8
13
712927
1
FW .344 X 1.00 X.12 HRD Z
14
602867
1
SPACER, 1.00 OD X .109
15
602630
2
ROD END W STUD 1/4-28
16
058842
4
NT .250-28 HX JAM ZNYC
17
768515
11
FW .281 X .625 X .051/.080H
18
050161
2
CS .312-18 X 1.750 HX G5
19
034272
9
NT .312-18 HX G5 ZNYC
20
768523
16
FW .343 X .687 X .051/.080H
21
063198
2
CS 10-24 X .750 HXFLK ZN
22
602538
1
SWITCH PLUNGER, NC/NO
23
704916
1
CS .250-20 X 1.250 HX G5
24
024927
5
NT .250-20 HX GR.5 ZNYC
25
112492
1
BASEPLATE
26
601822
1
NUT PLATE, .420 CENTERS
27
058776
1
NT .312-18 HXZY NL
NOTES:
1. Part of cable.
