Fuel system – Hustler Turf 1500 User Manual
Page 55
114443_1011
6-11
Fuel System
INDEX NO.
PART NO.
QTY.
DESCRIPTION
9
602702
1
FUEL TANK
10
602703
1
REAR COVER
11
602916
1
RATCHETING GAS CAP, 3.5"
12
714998
2
MS #10-24 X .625 HX ZN
13
773523
1
KEEPER, FLEXDRAW #37-25
14
704932
2
FW .219 X .500 X .048 ZNYC
15
059832
2
NT #10-24 HX NL ZN
16
773416
1
FLEX DRAW LATCH
17
601089
2
RIVET .188 DIA BLK HD
18
033001
3.25’
TRIM
19
601069
2
CN .312-18 X .200 MAX THK
20
113273
1
COVER LATCH PLATE
21
768523
4
FW .343 X .687 X .051/.080H
22
036236
4
CS .312-18 X 1.000 HX G5
23
808485
2
RIVET NUT, 5/16-18 THREAD
24
113275
1
REAR COVER MOUNT
25
712919
3
FW .406 X 1.00 X.12 HRD Z
26
000331
1
WIRE TIE, SMALL/SHORT
27
115684
1
FUEL TANK SUPPORT
28
603161
1
VACUUM BREAKER FILTER
29
603158
1
ROLLOVER VALVE & GROMMET
30
785295
1
SUCTION HOSE GROMMET
31
601527
1
SUCTION HOSE 19.5
NOTES:
CUT TRIM LENGTHS
A
3"
TWO (2) PIECES
B
10"
TWO (2) PIECES
C
13"
ONE (1) PIECE
