HP vs80 User Manual
Page 63
Chapter 4
Diagnostics and Troubleshooting 63
5. Loosen the autoloader cover by removing the five screws on the back of
the autoloader, and the screws on each side of the autoloader.
Figure 15
Remove Indicated Back Cover Screws
6. Remove the top cover by lifting it from the back and easing it out from
under the front panel display cover.
