18
Table 3 - OmniBook 5500 Parts Identification
Description Part Number Exchange Part # User Replace.
1 Bezel F1320-60958 N
2 CPU Module
CPU Module/100C F1320-60901 F1320-69001 N
CPU Module/120C F1320-60902 F1320-69002 N
CPU Module/133C F1320-60903 F1320-69003 N
3 Dock Grounding Spring Plate F1320-60962 N
4 Expansion Door F1125-60920 Y
5 FFC Cable T/B to M/B 10 PIN F1320-60950 N
6 3.5" floppy disk drive F1195-60901 Y
7 HDD-FPC Flex F1320-60961 N
8 Hard Disk Drive
HDD Drive 810MB F1191-60901 F1191-69001 Y
HDD Drive 1.35GB F1192-60901 F1192-69001 Y
HDD Drive 2.0GB F1339-60901 F1339-69001 Y
9 HDD PCB Bracket F1320-60965 N
10 HDD Plastic Kit F1320-60947 Y
11 HDD Security Cover F1320-40001 Y
12 Heat Pipe F1320-60964 N
13 Heat Pipe Bracket F1320-60972 N
14 Heat Pipe Spreader F1320-60921 N
15 Heat Sink F1320-60954 N
16 Icon Assembly F1320-60918 N
17 I/O Bracket Grounding Clip F1350-60912 N
18 I/O Door F1320-60928 Y
19 IR Lens F1320-60952 N
20 KBD Shielding Plate F1320-60960 N
21 Keyboard * N
22 LCD Display
LCD Assy 10.4” TST/S F1320-60904 F1320-69004 N
LCD Assy 11.3” DSTN/S F1320-60905 F1320-69005 N
LCD Assy 12.1" TFT/S F1320-60906 F1320-69006 N
LCD Assy-SMG 12.1" TFT/S F1320-60994 F1320-69094 N
23 Lower Chassis Case F1320-60930 N
24 Memory Cover Door F1320-60927 Y
25 Memory Module
8MB RAM F1134-60901 F1134-69001 Y
16MB RAM F1135-60901 F1135-69001 Y
32MB RAM F1136-60901 F1136-69001 Y
26 Microphone Assembly F1081-60946 N
27 Palmrest2 Assembly F1320-60986 N
28 PCA - DC Power Supply F1320-60925 N
29 PCA PB-586/IO Bracket F1320-60926 F1320-69026 N
30 PCA PB-Icon Board
PCA PB-ICON F1320-60924 N
PCA PB-ICON/SMG F1320-60993 N
31 PCMCIA Button Assembly F1320-60949 Y
32 Plastic Foot F1320-60929 Y
33 Printer Port Door F1125-60918 Y
34 Prog Flash IC, BIOS F1321-60907 N
35 Rubber Foot F1320-60957 Y
36 Screw - CPU M2 X 4L F1320-60963 N
37 Screw - CPU M2.6 X 6L F1081-60942 N
38 Screw - HDD Door F1320-60919 Y
39 Screw - ISOP M2.0x6.0L Nylok F1350-60924 N
40 Screw - ISOP M2.6X8L Nylok F1081-60939 N
41 Screw - M2.6x4.0L F1350-60927 N
42 Screw - Keyboard F1320-60920 N
43 Standoff-M2x11.75 Nyl F1320-60951 N
44 Standoff-M2x15L Nyl F1320-60955 N
45 Std Li-Ion Battery F1193-60902 Y
46 Sub Battery 4.8v F1081-60925 N
47 Upper Chassis Case F1320-60931 N
Note, this is a partial parts list. For a complete parts list, please refer to Appendix E or the Product Support Plan.
*For a complete listing of available localized keyboards, refer to Appendix E or the Product Support Plan.
